Customizable Vapour barrier 1.5*50m is a lightweight, reinforced, polyethylene vapour control layer for use within roof and wall constructions

Customizable Vapour barrier 1.5*50m is a lightweight, reinforced, polyethylene vapour control layer for use within roof and wall constructions

Introduction

Product General Information:

Place of Origin:	Jiangsu China
Brand Name:	Kingway
Model Number:	UB80
Certification:	CE
Weight:	80g
Roll Length:	50m/Roll or Customized
Roll Width:	1.5m or Customized
Specification:	1.5*50m

Commercial Terms of Products:

Minimum Order Quantity:	10000 square meters
Packaging Details:	Plastic / Thermoplastic Packaging
Delivery Time:	30-45days
Payment Terms:	30%T/T,70% after shipment
Supply Ability:	1000000 Square

Description:

Vapour Control Membrane is a pitched roofunderlay enables airtightness and vapour control in roof and wall constructions. It has an optimum fixed vapour resistance level of Sd 10m. This allows for an ideal level of vapour control, by preventing diffusion of internal vapour into the building envelope and prevents a build-up of condensation within the building envelope, which can cause mildew growth and structural damage. The CE sign in accordance with DIN 13984 gives the necessary assurance for the quality of the product.

Applications:

Interior installation to create an airtight envelope

All construction types.

Ceilings, walls, floors and loft spaces.

Specifications:

Project	UB80
Colour	White or Others
Resistance to Fire	Class E
Material	Airtight Membrane
System	Airtight
Elongation Longitudinal(%)	120
Elongation Transverse(%)	110
Tear Resistance Longitudinal(N/50mm)	110
Tear Resistance Transverse(N/50mm)	95
Tensile Strength Longitudinal(N/50mm)	80
Tensile Strength	120
Transverse(N/50mm)	120
Water Vapour Resistance - Sd Value (m)	10m, Fixed
Water Penetration Resistance	Class W1
Application Area	Ceiling, Floors, Internal Wall, Loft Space

Competitive Advantage:

Lightweight, flexible and moisture resistant.

Improves airtightness and thermal performance.

Increases building energy efficiency.

Water vapour transmission fixed Sd value 10m.

Reduces draughts and heat loss.
